gear unit/rotary drilling rig power head,hydraulic earth drill

FOB Reference Price:Get Latest Price
$2,000.00 - $25,000.00 / Sets | 1 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
LYD
Model Number:
LYD3000
Name:
Hydraulic Earth Drill
Application:
Tree planting,Telecom,Municipal garden,Highways,Railway,Photovoltaic
Working Medium:
Soil,Frozen Earth,Soil With The Rock
Power System:
Hydraulic
Excavator Weight:
2-4Ton
Hole Depth:
0.5m~3m Or As Your Request
Hole Diameter:
100~1200mm Or As Your Request
Condition:
New
OEM:
Available
Supply Ability
Supply Ability:
30 Set/Sets per Month Hydraulic Earth Drill
Packaging & Delivery
Packaging Details
Packed With Standard Wooden Box
Port
ShangHai Or As Your Request
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Video Description

gear unit/rotary drilling rig power head,hydraulic earth drill



Product Description

Hydraulic earth drill/auger is mainly composed with power head and auger. The power head and auger are fixed together. Auger is composed of screw blade and bit on the end of the auger, there is also teeth on the end of the auger. Simple construction, stronger drill ability, low production cost, high flexibility.



Applications:

Tree planting;

Telecom;

Electric power;

Municipal garden;

Highway;

Railway;

Photovoltaic ect

Hydraulic Earth Drill  Details

Model

Unit

BY-AD60

BY-AD80

BY-AD150

BY-AD200

BY-AD300

Excavator Application

T

 2-6T

6-15T

 15-20T

20-25T

25-40T

Torque

Nm

1094-4117

2570-9961

5307-20998

8314-30393

27198-59403

Pressure

Bar

80-240

80-240

80-260

80-260

160-350

Flow

Lpm

25-92

40-150

80-170

80-170

100-250

Rotate speed

Rpm

30-68

20-48

15-48

12-26

10-22

Output shaft

mm

65Rnd

75Sq

75Sq

75Sq

110Sq

Weight

kg

110

115

200

298

721

Max Auger Diameter clay/Shale

mm

300

800

1100

1200

1500

Max Auger Diameter Earth

mm

500

1000

1500

1600

2000



Hydraulic Earth Drill Pipe:

Ordinary drill pipe(including drill teeth and drill bit)
Wear-resisting drill pipe (including carbide teeth and carbide drill)
Soft rock drill pipe(including rock teeth and rock drill)



Hydraulic Earth Drill Pipe Diameter:

S4 : 100mm,150mm,200mm,225mm,250mm,300mm,350mm,

        400mm,450mm,500mm,600mm,750mm,900mm

S5: 150mm,200mm,225mm,250mm,300mm,350mm,400mm,
        450mm,500mm,600mm,750mm,800mm,900mm

S6 : 150mm,200mm,225mm,250mm,300mm,350mm,400mm,
        450mm, 500mm,600mm,750mm,800mm,900mm,1m,1.2m

Please click products below to see more details

Main products

Trade show
Company Information

WuXi Lydite is a professional high tech enterprise based in Wu xi with an area of 5000 square meters workshop. It is established in 2000 and has convenient transportation access. We are fully committed to producing technologically advanced excavator parts and we have our own technical engineering research center and pile driving machinery engineering center. Our core team is composed of senior staff in the industry and has the international advanced R&D system and technical level. We are concerned on research and development to ensure that we can provide our customers with top quality and the innovative products.

Packaging & Shipping

According to the weight and volume : pallet, carton , wooden case or as requests We accept different shipping line, air express by DHL,FEDEX,TNT,EMS...

We guarantee the product delivery will be strictly on time

Our Services

1.R&D Team:

Our company has a highly skilled and professional R&D team. We always adhere to continuous innovation and the pursuit of excellence in developing our products.


2.Quality assurance:
Our company has one of the most stringent quality control systems, from our feed testing and product inspection to the final inspection process. Strict quality process control and management ensures product quality and accountability.

3.Inspection of Raw Materials:
Our Company has a professional metal analysis room and advanced preliminary heat-treatment equipment. We have strict standards when inspecting the material of each our products.

4.Production Equipment:
We have highly advanced precision manufacturing equipment which are produced in countries such as Germany, Switzerland, and Japan with strict control  of excellence.

5.Our gearbox is constructed as a lightweight component with a compact structure. It consists of a wide range of reduction ratios, output torque, smooth motion, impact resistance, braking power, reliability, durability, and so on.  Our power head has two class of swing assy and the output shaft is not fixed so that when it is broken, you don't need to change the whole body.

6.Warranty:
We offer 6 months warranty time for the power head.
